RemoteAccess-Workplace

Item no. A3300009
Back to last view
HDMI 2.0Displayport™ 1.24K / UHDCompressedEmbeddedAnalog Network connection (including monitoring)
Counterpart to the RemoteAccess-GATE, with multiviewer functionality
Request product now
Add to watchlistCompare productQuestions about the product?
Learn more
Close
The form could not be loaded.

The RemoteAccess-Workplace

serves as a hardware counterpart to the RemoteAccess-GATE and offers the user powerful IP access to computers or servers connected to the RemoteAccess-GATE. The standalone device can be used whenever troublefree IP access is required, plus it comes with multiviewer functionalities. When using several RemoteAccess-GATEs, it is possibleto access, display and control several servers simultaneously, distributed over up to 3 monitors.

Video
  • Resolution up to
    3840 × 2160 @ 60 Hz
Signals
  • Embedded stereo audio (2 channel LPCM)
Device
  • The device can be located on the desk, mounted in a standard 19“ rack or attached to the back of a monitor via VESA.
Warranty
  • A 2-year, free of charge product guarantee
Operation features
  • Each RemoteAccess-Workplace can establish up to 8 parallel sessions to different RemoteAccess-GATES at the same time.
  • Via previously configured hotkeys or the so-called Port Navigator, connected RemoteAccess-GATEs and Remote Sessions can be accessed.
  • The PiPs (picture in picture) can be freely arranged on up to three 4K monitors.
  • The user has the option to scale and overlap the windows.
  • A built-up screen layout can be saved, recalled with a HotKey or preconfigured as a preset for the user.
  • Flexible arranges monitors can be operated with one set of keyboard and mouse.
  • The device also offers touch screen support.
  • The RemoteAccess-Workplace can be fully integrated into a KVM matrix system via remote access, enabling complex multi-video applications or CrossDisplay-Switching workstations.
  • USB signals from connected peripherals, e.g. USB sticks or USB headsets, are forwarded to the source of the RemoteAccess-GATE via the RemoteAccess-Workplace.
System expansion
  • By combining several RemoteAccess-Workplaces, access to additional RemoteAccess-GATEs or remote sessions is enabled. Logical workplaces can also be configured in this case, operable with one keyboard and mouse.
GeneralProduct group RemoteAccess
Product Family RemoteAccess-Workplace
Number of workstations 1
Power Supply no redundancy
Input optionsUSB mouse yes
USB keyboard yes
Video output 1Quantity 1
Format HDMI 2.0
Colour depth 24 bit
Pixel rate ca. 25 MPixel/s to 594 MPixel/s
Vertical frequency 24 Hz to 75 Hz
Horizontal frequency 25 kHz to 135 kHz
Exemplary resolutions 3840 × 2160 (60 Hz)
3840 × 2160 (30 Hz)
2560 × 1600 (60 Hz)
1920 × 1080 (60 Hz)
640 × 480 (60 Hz)
General Notes Further VESA and CTA standardised resolutions possible within pixel rate and horizontal/vertical frequency.
Video output 2Quantity 1
Format DisplayPort 1.2
Colour depth 24 bit
Pixel rate ca. 25 MPixel/s to 594 MPixel/s
Vertical frequency 24 Hz to 75 Hz
Horizontal frequency 25 kHz to 135 kHz
Exemplary resolutions 3840 × 2160 (60 Hz)
3840 × 2160 (30 Hz)
2560 × 1600 (60 Hz)
1920 × 1080 (60 Hz)
640 × 480 (60 Hz)
General Notes Further VESA and CTA standardised resolutions possible within pixel rate and horizontal/vertical frequency.
Audio 1Transmission type Stereo
2-channel LPCM
Resolutions 16 bit
Sampling rate up to 32 kHz
up to 44.1 kHz
up to 48 kHz
Audio support Digital Embedded
Audio 2Transmission type Stereo
Resolutions 16 bit
20 bit
Sampling rate 48 kHz
96 kHz
Audio support Analog
NetworkQuantity 2
Medium CAT5
CAT6
CAT7
Data rate 10 Mbit/s
100 Mbit/s
1 Gbit/s
MaintenanceUpdate via WebIF (Network)
HousingMaterial Steel sheet
Width ca. 165 mm
Height ca. 44 mm
Depth ca. 190 mm
IP protection class IP20
Weight ca. 1.29 kg
Operating conditionsOperating temperature 0 °C to 40 °C
Operating air humidity, non-condensing 20 % to 80 %
Area of application Indoor use
Maximum operating altitude above sea level 2,000 m
Storage temperature 0 °C to 50 °C
Storage air humidity, non-condensing 15 % to 80 %
MTBF 46,624 h at 25°C
Conformities CE compliant (see downloads)
UKCA compliant (see downloads)
FCC compliant (see manual)
EAC compliant (see downloads)
RoHS compliant (see downloads)
WEEE (reg. no. DE30763240)
REACH compliant (see downloads)
Power supplyQuantity 1
Type External
Input voltage 19 VDC
Current consumption 4.74 A
