RemoteAccess-GATE

Item no. A3300008
Back to last view
HDMI 1.42KCompressedEmbedded Network connection (including monitoring)Local workspace
Stand-alone device serving as a link between a G&D KVM system and the network world
Request product now
Add to watchlistCompare productQuestions about the product?
Learn more
Close
The form could not be loaded.

Thanks to the RemoteAccess-GATE,

you have worldwide access to your KVM systems. In the fast-moving digital world, the ability to link company sites around the world and access computer systems at different locations from anywhere is becoming more important than ever. As a stand-alone device, the RemoteAccess-GATE connects the two worlds of KVM and network. In this context, "GATE" stand for "Global Access to Enterprise" and therefore for worldwide access to your KVM systems. The RemoteAccess-GATE opens up completely new ways of remote operation from remote locations, and also improves the ways of providing IT support and collaboration between employees.

Video
  • Supports multi-head/multi channel: multi-head video signals can be shown on the remote side and can be operated seamlessly with a single set of keyboard and mouse (with a separate RemoteAccess-GATE for each video signal)
  • Resolution up to
    2560 × 1600 @ 60 Hz,
    4096 × 2160 @ 30 Hz
  • Resolution up to
    2560 × 1600 @ 60 Hz,
    4096 × 2160 @ 30 Hz
Signals
  • Embedded stereo audio (2 channel LPCM)
Device
  • Stand-alone device
  • External power supply
Warranty
  • A 2-year, free of charge product guarantee
Security features
  • AES encryption
  • LDAP, Active Directory and RADIUS directory server integration
  • User/group privileges
  • IP access controls
  • Login limitations
  • KVM session encryption
  • SSL Certificates
  • Configurable security banner
  • Audit log
  • SNMP/Syslog event logging and notifications
  • Strong passwords
Operation features
  • RemoteAccess-GATE provides configurable bandwidths to work over the Internet, LAN or WAN and to enable remote IT support at any time. You can use the device to connect to a single remote computer or to the entire KVM system.
  • In addition, up to eight users can access it simultaneously.
  • Being a flexible IP solution, you can use RemoteAccess-GATE via G&D console modules, laptop or PC.
  • Configuration is possible via HTML browser or via the serial service interface.
  • Software/web clients on PCs (CON functionality) connect to the RemoteAccess-GATE via the Internet, WAN or LAN. This enables secure remote access to computer signals and G&D console modules.
  • For best possible results, the following three web clients are available:
    • HKC (HTML KVM Client) – Operating system independent, without Java; standard client
    • AKC (Active KVM Client) – Windows without Java; can only be used with Internet Explorer or Edge Legacy Browser (click-once application)
    • VKC (Virtual KVM Client) – Windows, Linux or Mac OS with Java 1.8 (no openJDK)
Signals
  • Adapters available for VGA, DVI, Mini DisplayPort and USB-C.
  • USB data: With the use of additional hardware, USB data can be transferred from the remote workplace via the RemoteAccess-GATE and the KVM installation to the local computer.
GeneralProduct group RemoteAccess
Product Family RemoteAccess-GATE
Number of workstations 1
Power Supply no redundancy
Input optionsUSB mouse yes
USB keyboard yes
Video inputQuantity 1
Format HDMI 1.4
Colour depth 24 bit
Pixel rate ca. 25 MPixel/s to 297 MPixel/s
Exemplary resolutions 4096 × 2160 (24 Hz)
4096 × 2160 (25 Hz)
4096 × 2160 (30 Hz)
3840 × 2160 (24 Hz)
3840 × 2160 (25 Hz)
3840 × 2160 (30 Hz)
2048 × 2160 (60 Hz)
2048 × 2048 (60 Hz)
2560 × 1600 (60 Hz)
1920 × 1200 (60 Hz)
1920 × 1080 (60 Hz)
General Notes Further VESA and CTA standardised resolutions possible within pixel rate and horizontal/vertical frequency.
Video outputQuantity 1
Format HDMI 1.4
Colour depth 24 bit
Pixel rate ca. 25 MPixel/s to 297 MPixel/s
Exemplary resolutions 4096 × 2160 (24 Hz)
4096 × 2160 (25 Hz)
4096 × 2160 (30 Hz)
3840 × 2160 (24 Hz)
3840 × 2160 (25 Hz)
3840 × 2160 (30 Hz)
2048 × 2160 (60 Hz)
2048 × 2048 (60 Hz)
2560 × 1600 (60 Hz)
1920 × 1200 (60 Hz)
1920 × 1080 (60 Hz)
General Notes Further VESA and CTA standardised resolutions possible within pixel rate and horizontal/vertical frequency.
AudioTransmission type Stereo
2-channel LPCM
Resolutions 16 bit
Sampling rate up to 32 kHz
up to 44.1 kHz
up to 48 kHz
Audio support Digital Embedded
NetworkQuantity 1
Medium CAT5
CAT6
CAT7
Data rate 1 Gbit/s
100 Mbit/s
10 Mbit/s
MaintenanceUpdate via WebIF (Network)
Serviceport settings 115200bps (8/N/1)
HousingMaterial anodised aluminium
Width ca. 160 mm
Height ca. 44 mm
Depth ca. 144 mm
IP protection class IP20
Weight ca. 0.71 kg
Operating conditionsOperating temperature 0 °C to 40 °C
Operating air humidity, non-condensing 20 % to 80 %
Area of application Indoor use
Maximum operating altitude above sea level 3,048 m
Storage temperature -20 °C to 60 °C
Storage air humidity, non-condensing 15 % to 80 %
MTBF 350,000 h at 25°C
Conformities CE compliant (see downloads)
UKCA compliant (see downloads)
FCC compliant (see manual)
EAC compliant (see downloads)
RoHS compliant (see downloads)
WEEE (reg. no. DE30763240)
REACH compliant (see downloads)
Power supplyQuantity 1
Type External
Input voltage 5 VDC
Current consumption 4 A
Power consumption idle 4.13 W
Power consumption max. 7.5 W
Heat output idle 4.13 W
Heat output max. 6.5 W
