extend keyboard, video, and mouse signals, as well as other peripheral data (e.g., audio and USB), via a dedicated CAT or fiber connection (up to 10,000 m). An extender system consists of a computer module (CPU) and a compatible console module (CON). Computers can be controlled in near real-time – both in extender and matrix applications. The DP-HR-CON series supports DisplayPort 1.1 for high-resolution video up to 2560 × 1600 (60 Hz) or 4096 × 2160 (30 Hz). Video data is processed pixel-perfectly and offers excellent hand-eye coordination, thanks to bluedec™ – G&D's advanced, multi-stage, lossless compression technology.
Access to standard interfaces of the computer, with no software installation required
| General | Product group |
KVM extenders |
|---|---|---|
| Product Family |
MTX-CPU/CON | |
| Number of workstations |
1 | |
| KVM matrix system component |
Console module (digital) | |
| Power Supply |
Redundancy without load balancing | |
| Input options | USB mouse |
yes |
| USB keyboard |
yes | |
| PS/2 mouse |
yes | |
| PS/2 keyboard |
yes | |
| Transmission | Number of transmission channels |
2 |
| Redundant transmission channels |
no redundant KVM transmission | |
| Range |
100 m (62.5/125µm) 200 m (50.0/125µm, OM2) 400 m (50.0/125µm, OM3) 70 m (62.5/125µm) 150 m (50.0/125µm) 400 m (50.0/125µm, OM4 - 4700MHz*km) | |
| Laser class |
Class 1 | |
| Type of interface |
LC-Duplex | |
| Wavelength |
850 nm | |
| Medium |
Fiber MM | |
| Data rate |
2.5 Gbit/s | |
| Video output | Quantity |
2 |
| Format |
DisplayPort 1.1 (HBR) | |
| Colour depth |
24 bit | |
| Pixel rate ca. |
25 MPixel/s to 300 MPixel/s | |
| Vertical frequency |
24 Hz to 120 Hz | |
| Horizontal frequency |
25 kHz to 135 kHz | |
| Exemplary resolutions |
4096 × 2160 (30 Hz) 4096 × 2160 (25 Hz) 4096 × 2160 (24 Hz) 3840 × 2160 (30 Hz) 3840 × 2160 (25 Hz) 3840 × 2160 (24 Hz) 2560 × 1600 (60 Hz) 2048 × 2048 (60 Hz) 1920 × 1200 (60 Hz) 1920 × 1080 (60 Hz) | |
| General Notes |
Further VESA and CTA standardised resolutions possible within pixel rate and horizontal/vertical frequency. | |
| Supported industry standards |
Display Data Channel Command Interface (DDC/CI) Display Data Channel (DDC) Extended Display Identification Data (EDID) | |
| Audio 1 | Transmission type |
Bidirectional Stereo |
| Resolutions |
24 bit digital | |
| Sampling rate |
up to 96 kHz | |
| Bandwidth |
22 kHz | |
| Audio support |
Analog | |
| Audio 2 | Transmission type |
Stereo 2-channel LPCM |
| Resolutions |
24 bit 20 bit 16 bit | |
| Sampling rate |
up to 48 kHz | |
| Audio support |
Digital Embedded | |
| USB | Specification |
USB 2.0 |
| Medium |
Embedded | |
| Transmission rate |
max. 16 Mbit/s (app. Full Speed) | |
| Range |
max. 400 m | |
| USB classes |
All | |
| Maintenance | Update via |
Update Wizard (service interface) |
| Serviceport settings |
115200bps (8/N/1) | |
| Housing | Material |
anodised aluminium |
| Width ca. |
270 mm | |
| Height ca. |
44 mm | |
| Depth ca. |
210 mm | |
| IP protection class |
IP20 | |
| Weight ca. |
1.6 kg | |
| Operating conditions | Operating temperature |
5 °C to 45 °C |
| Operating air humidity, non-condensing |
20 % to 80 % | |
| Area of application |
Indoor use | |
| Maximum operating altitude above sea level |
3,000 m | |
| Storage temperature |
-20 °C to 60 °C | |
| Storage air humidity, non-condensing |
15 % to 85 % | |
| MTBF |
200,000 h at 25°C | |
| Conformities |
CE compliant (see downloads) UKCA compliant (see downloads) FCC compliant (see manual) TAA compliant (see downloads) EAC compliant (see downloads) RoHS compliant (see downloads) WEEE (reg. no. DE30763240) REACH compliant (see downloads) | |
| Power supply 1 | Quantity |
1 |
| Type |
Internal | |
| Input voltage |
100-240 VAC | |
| Input frequency |
60-50 Hz | |
| Current consumption |
0.7-0.3 A | |
| Power consumption max. |
33.4 W | |
| Heat output max. |
17.9 W | |
| Power supply 2 | Quantity |
1 |
| Type |
External | |
| Input voltage |
12 VDC | |
| Current consumption |
2.8 A | |
| Power consumption max. |
29.7 W | |
| Heat output max. |
14.2 W |
