is a device for splitting USB HID signals. The device can divide different data streams, which are transferred on one or two USB cables, to several USB outputs.
| General | Product group |
KVM add-ons |
|---|---|---|
| Product Family |
USB-Splitter-2 | |
| Power Supply |
no redundancy | |
| Maintenance | Update via |
Update Wizard (service interface) |
| Serviceport settings |
115200bps (8/N/1) | |
| Housing | Material |
anodised aluminium |
| Width ca. |
105 mm | |
| Height ca. |
26 mm | |
| Depth ca. |
124 mm | |
| IP protection class |
IP20 | |
| Weight ca. |
0.21 kg | |
| Operating conditions | Operating temperature |
5 °C to 45 °C |
| Operating air humidity, non-condensing |
20 % to 80 % | |
| Area of application |
Indoor use | |
| Maximum operating altitude above sea level |
3,000 m | |
| Storage temperature |
-20 °C to 55 °C | |
| Storage air humidity, non-condensing |
15 % to 80 % | |
| MTBF |
200,000 h at 25°C | |
| Conformities |
CE compliant (see downloads) UKCA compliant (see downloads) EAC compliant (see downloads) | |
| Power supply | Quantity |
1 |
| Type |
External | |
| Input voltage |
12 VDC | |
| Current consumption |
0.6 A | |
| Power consumption max. |
7.2 W | |
| Heat output max. |
2.2 W |
