enables shortcuts to be transferred to any G&D device by pressing a button/panel.For this purpose, the HK-Controller provides potential-free contacts to which any buttons/panels can be connected. Inputs via a panel are converted into a HotKey sequence in the HK-Controller and sent to the connected G&D device as a control command.
| General | Product group |
KVM add-ons |
|---|---|---|
| Product Family |
HK-Controller | |
| Power Supply |
no redundancy | |
| Input options | USB keyboard |
yes |
| PS/2 keyboard |
yes | |
| Maintenance | Update via |
Update Wizard (service interface) |
| Serviceport settings |
115200bps (8/N/1) | |
| Housing | Material |
anodised aluminium |
| Width ca. |
105 mm | |
| Height ca. |
26 mm | |
| Depth ca. |
104 mm | |
| IP protection class |
IP30 | |
| Weight ca. |
0.24 kg | |
| Operating conditions | Operating temperature |
5 °C to 45 °C |
| Operating air humidity, non-condensing |
20 % to 80 % | |
| Area of application |
Indoor use | |
| Maximum operating altitude above sea level |
3,000 m | |
| Storage temperature |
-20 °C to 60 °C | |
| Storage air humidity, non-condensing |
15 % to 80 % | |
| MTBF |
150,000 h at 25°C | |
| Conformities |
CE compliant (see downloads) UKCA compliant (see downloads) FCC compliant (see manual) TAA compliant (see downloads) EAC compliant (see downloads) RoHS compliant (see downloads) WEEE (reg. no. DE30763240) REACH compliant (see downloads) | |
| Power supply | Quantity |
1 |
| Type |
External | |
| Input voltage |
12 VDC | |
| Current consumption |
0.5 A | |
| Power consumption idle |
1.08 W | |
| Power consumption max. |
5.52 W | |
| Heat output idle |
1.1 W | |
| Heat output max. |
5.52 W |
