DVI-FiberLink(M) incl. PowerPack

Item no. A2300052
Back to last view
Media converter CAT to Fiber 1G multimode
Request product now
Add to watchlistCompare productQuestions about the product?
Learn more
Close
The form could not be loaded.

The DVI-FiberLink

increases the system range within a digital matrix system. A DVI-FiberLink system consists of two identical modules (transceivers) that act as media converters between CAT and fiber in both directions. The DVI-FiberLink pair is placed at any position, on the computer or user side of the matrix switch between two system components. One access is extended per DVI-FiberLink pair.

Transmission
  • The transmission distance is up to 550 meters over fiber multimode optics, incl. transmission module(s)/SFP transceiver(s)
Device
  • Active media converter from CAT to fiber
  • External power supply
Operation
  • The device can be placed between the following components:
    • Two digital matrix switches
    • A computer module (e. g. DVI-CPU) and a digital matrix switch
    • A console module (e. g. DVI-CON) and a digital matrix switch
Warranty
  • A 3-year, free of charge product guarantee
  • For an additional fee guarantee extensioin/guarantee renewal possible
Device
  • External power pack supplies up to five modules with power via the power loop function
GeneralProduct group KVM add-ons
Product Family DVI-FiberLink
Power Supply no redundancy
MaintenanceUpdate via Update Wizard (service interface)
Serviceport settings 115200bps (8/N/1)
HousingMaterial anodised aluminium
Width ca. 105 mm
Height ca. 26 mm
Depth ca. 84 mm
IP protection class IP20
Weight ca. 0.22 kg
Operating conditionsOperating temperature 5 °C to 45 °C
Operating air humidity, non-condensing 20 % to 80 %
Area of application Indoor use
Maximum operating altitude above sea level 3,048 m
Storage temperature -10 °C to 60 °C
Storage air humidity, non-condensing 15 % to 80 %
MTBF 250,000 h at 25°C
Conformities CE compliant (see downloads)
UKCA compliant (see downloads)
FCC compliant (see manual)
TAA compliant (see downloads)
EAC compliant (see downloads)
RoHS compliant (see downloads)
WEEE (reg. no. DE30763240)
REACH compliant (see downloads)
Power supplyQuantity 1
Type External
Input voltage 12 VDC
Current consumption 0.3 A
Power consumption idle 1.3 W
Power consumption max. 2.4 W
Heat output idle 1.3 W
Heat output max. 2.4 W
