CAT-Repeater Basic

Item no. A2300087

Back to last view

Module to extend the transmission range between 2 CAT components of a digital matrix switch

Request product now

Add to watchlist Compare product Questions about the product?

Learn more

The form could not be loaded.

CAT-Repeater extension modules

let you extend the transmission range between two CAT components of a digital matrix switch. An expansion module adds 140 meters to the overall transmission distance. You can use up to five expansion modules on one line.

Transmission

The transmission distance is up to 140 meters over CAT

Device

PowerPack not included in the scope of delivery for Basic variants

Operation

The device can be placed between the following components:
- Two digital matrix switches
- A computer module (e. g. DVI-CPU) and a digital matrix switch
- A console module (e. g. DVI-CON) and a digital matrix switch

Device

External power pack supplies up to five modules with power via the power loop function

Device

External power supply via external 12V power pack or G&D-MultiPower, providing a central and redundant power supply

General	Product group	KVM add-ons
	Product Family	CAT-Repeater
	Power Supply	no redundancy
Maintenance	Update via	Update Wizard (service interface)
Maintenance	Serviceport settings	115200bps (8/N/1)
Housing	Material	anodised aluminium
	Width ca.	105 mm
	Height ca.	26 mm
	Depth ca.	84 mm
	IP protection class	IP20
	Weight ca.	0.23 kg
Operating conditions	Operating temperature	5 °C to 45 °C
	Operating air humidity, non-condensing	20 % to 80 %
	Area of application	Indoor use
	Maximum operating altitude above sea level	3,048 m
	Storage temperature	-10 °C to 60 °C
	Storage air humidity, non-condensing	15 % to 80 %
	MTBF	250,000 h at 25°C
	Conformities	CE compliant (see downloads) UKCA compliant (see downloads) FCC compliant (see manual) TAA compliant (see downloads) EAC compliant (see downloads) RoHS compliant (see downloads) WEEE (reg. no. DE30763240) REACH compliant (see downloads)
Power supply	Quantity	1
	Type	External
	Input voltage	12 VDC
	Current consumption	0.3 A
	Power consumption idle	1.3 W
	Power consumption max.	2.4 W
	Heat output idle	1.3 W
	Heat output max.	2.4 W
